33S/T1
If You Have Any Questions, Contact Us:
EMAIL US: info@Dustfumemist.comor CALL US: +1 (833) 487-8387
NOTE: Drum Not Included
| Model | Motor hp | Maximum CFM (note 1) | SP (note 2) | dBA @ 5' | Blower Wheel Diameter | Hose Size | Inlet Nozzle Size | Maximum Drum Diameter | 115V 1 Ph | 230/460 3 Ph |
|---|---|---|---|---|---|---|---|---|---|---|
| 33S | 1/3 | 335 | 3" | 76 | 8" | 3" x 60" | 4" x 4" | 20 1/2" | 5.8 | 1.8 |
| 50S | 1/2 | 450 | 7" | 78 | 9 3/4" | 4" x 60" | 5" x 5" | 20 1/2" | 8.8 | 1.9 |
| 75S | 3/4 | 580 | 7" | 78 | 10 5/8" | 4" x 60" | 5" x 5" | 20 1/2" | 8.8 | 2.4 |
| 100S | 1 | 700 | 4 1/2" | 83 | 10 5/8" | 5" x 60" | 6" x 6" | 24" | 11.2 | 3.2 |
| 150S | 1 1/2 | 875 | 6 1/2" | 76 | 11" | 6" x 60" | 7" x 7" | 24" | 16.0 | 4.4 |
| 200S | 2 | 1100 | 8 1/2" | 85 | 12 1/4" | 6" x 60" | 7" x 7" | 24" | 20.0 | 5.6 |
| 300S | 3 | 1300 | 10" | 84 | 13" | 6" x 60" | 7" x 7" | 24" | 7.6 |
NOTES: Drum Not Included
1. Maximum CFM at 0” SP (clean drum, dust bag and with 5 feet of inlet hose and inlet nozzle).
2. Maximum additional static pressure at which point there will be no air flow.
3. Minimum micron size that standard dust bag will capture 99%.
